A2 UV flatbed printer with the lid open, showing the print carriage and 500 x 400 mm bed

UV flatbed printers

A2 UV Flatbed Printer 5040 (500 × 400 mm)

Models · 5040

An A2 UV flatbed printer for batch production: a 500 × 400 mm bed, 150 mm print height and one or two Epson heads, so it prints phone cases, bottles, gifts, signs and panels in larger batches than our desktop models. It runs CMYK, CMYK + white or double CMYK with a circulating ink system, an automatic lifting platform and UltraPrint RIP software. Compared with the A3 model it has a larger bed, 30 mm more print height and an optional second head.

Print size
500 × 400mm
Print height
150mm
Resolution
2880 × 1440dpi
Weight
70kg
Get a quote Test my part on it
  • 2-year whole-machine warranty
  • Free operator training
  • Built to order: voltage, plug, labels
  • 500 × 400 mm bed and 150 mm print height
  • One or two Epson heads: CMYK, CMYK + white or double CMYK
  • Variable droplet from 2.5 to 12 pl
  • Automatic platform lifting
  • Circulating ink supply with built-in emergency ink pump

Overview

The A2 UV flatbed printer prints directly onto objects placed on its 500 × 400 mm bed. UV light cures the ink during printing, so prints come off dry and scratch-resistant. With 150 mm of print height and an automatically lifting platform, it handles thick items such as bottles, boxes and blocks as well as flat panels. It is designed for batch production: you can fill the bed with phone cases or tags and print them in one run.

The printer takes one or two Epson heads, each with 8 rows of 180 nozzles and a variable droplet from 2.5 to 12 pl. Colour options are CMYK, CMYK + white (one head for colour, one for white) or double CMYK. White ink enables relief effects and printing on dark or clear materials.

Configuration

  • Heads: 1 or 2 Epson heads.
  • Ink: 1 L × 4 colours or 220 ml × 8 colours with a continuous circulating supply; fixed ink tanks that do not leak when moved; integrated waste-ink tank.
  • Ink extraction: sliding ink stack with an independent pump and a built-in emergency pump.
  • Motion: toothed X-axis beam; Y-axis on two linear guides with four interlocking blocks.
  • Safety: tinted front cover that blocks UV light; ventilated floating side covers.
  • Software: UltraPrint RIP on Windows; high-speed USB.
  • Power: AC 220 V or 110 V, 50–60 Hz.
  • Size and weight: 1000 × 750 × 650 mm, 70 kg.

Typical applications

Phone cases, bottles, gifts, promotional items, signs, advertising panels, decorative glass, screens, leather and wallpaper samples. Single pieces cost the same to set up as large batches, so it also suits one-off personalisation.

Options and customization

  • One or two heads and colour configuration.
  • 220 V or 110 V supply and plug to suit your country.

We provide video tutorials, installation guidance and training until your operators work confidently.

Talk to an engineer

Tell us the material, thickness and the result you need. An engineer replies with a matched configuration and a quote.

Send your job details

Need a different setup?

This site shows only part of our range. Other powers and sizes, custom builds and everything around the machine are available on request.

Ask for the rest

Related guide

Wall printer buyer’s guide

Data

Specifications

A2 UV Flatbed Printer 5040 (500 × 400 mm) specifications
Print size500 × 400 mm
Print height150 mm
PlatformAutomatic lifting
Print heads1 or 2 Epson heads, 8 rows × 180 nozzles each
Ink dropletVariable, 2.5–12 pl
Colour configurationCMYK; CMYK + white; 2 × CMYK
Resolution360, 720, 1440 or 2880 dpi modes; up to 2880 × 1440 dpi
Print speed8 m²/h at 720 × 720 dpi (4 pass); 4 m²/h at 1440 × 720 dpi (8 pass); 2 m²/h at 1440 × 1440 dpi (16 pass); 1.8 m²/h at 2880 × 1440 dpi (32 pass)
Ink system1 L × 4 colours or 220 ml × 8 colours; continuous circulating supply
File formatsTIFF (RGB and CMYK), BMP, PDF, EPS, JPEG, AI, PSD
SoftwareUltraPrint RIP
Operating systemWindows
InterfaceHigh-speed USB
Power supplyAC 220 V or 110 V ±10 %, 50–60 Hz
Rated power100 W
Working environment15–35 °C, 20–80 % RH
Machine size (L × W × H)1000 × 750 × 650 mm
Weight70 kg

Speeds are the manufacturer's figures per pass mode; real output depends on the object, colour set and white layers.

Wuhan Maxwave Laser Technology Co., Ltd. · sales@zerolineai.com · +44 7762 362563 · Specifications may change; confirm your configuration with us.

Fit

Materials & uses

Materials

  • Glass
  • Leather
  • Plastics
  • Wallpaper and film
  • Sign boards

Applications

  • Phone cases
  • Bottles
  • Gifts and promotional items
  • Signs and advertising panels
  • Decorative glass and screens

FAQ

About this machine

Should I choose one head or two?

One head prints CMYK. Two heads let you print CMYK + white in one pass, or run double CMYK for more speed. Choose two heads if you print white on dark or clear items.

Can it print raised textures?

Yes. Layers of white ink build up a relief effect that you then print over in colour.

How fast is it?

8 m²/h at 720 × 720 dpi, 4 m²/h at 1440 × 720 dpi, 2 m²/h at 1440 × 1440 dpi and 1.8 m²/h at 2880 × 1440 dpi, per the manufacturer's sheet.

What software does it use?

UltraPrint RIP for colour management, on Windows. It accepts TIFF, BMP, PDF, EPS, JPEG, AI and PSD files.
