A5 UV flatbed printer with blue tinted lid and a printed phone case on the tray

UV flatbed printers

A5 UV Flatbed Printer MW-A5UV (Epson L800)

Models · MW-A5UV

Our smallest UV printer: a 20 kg desktop unit with a 120 × 210 mm print area for phone cases, cards and small gifts. It uses an Epson L800 head, prints white and colour in the same pass, measures object height (up to 120 mm) with a one-key infrared sensor and cures with an LED UV lamp. Choose it for counters, kiosks and start-up personalisation; the A3 and A2 models print larger items.

Print area: 120 × 210mm
Print height: 0–120mm
Weight: 20kg
Voltage: 100–230V

2-year whole-machine warranty
Free operator training
Built to order: voltage, plug, labels

Compact desktop unit: 500 × 370 × 270 mm, 20 kg
120 × 210 mm print area, objects up to 120 mm tall
Epson L800 head; white and colour in the same pass
One-key infrared height measurement
LED UV curing; prints are waterproof and scratch-resistant

Overview

The MW-A5UV is a desktop UV printer for small items. It prints a 120 × 210 mm area on objects up to 120 mm tall, so it handles phone cases, cards, tags and small gifts. Place the item on the tray, press the one-key infrared measurement, and the printer sets the right head height.

An Epson L800 head prints white and colour in the same pass. White lets you print bright colours on dark or transparent cases. An LED UV lamp cures the ink as it prints, so the result is dry, waterproof and scratch-resistant as soon as it leaves the tray. Ink use is about 20 ml per square metre.

Configuration

Head: Epson L800, micro-piezo.
Curing: LED UV lamp.
Height: one-key infrared measurement, 0–120 mm.
Lid: tinted cover over the print area.
Control: Windows PC.
Power: AC 100–230 V.
Size and weight: 500 × 370 × 270 mm, 20 kg; ships at 28 kg in a 530 × 400 × 300 mm wooden case.

Typical applications

Phone case personalisation, cards and tags, small gifts and promotional items. Its size suits retail counters, kiosks, print shops and start-up businesses.

If you need a bigger bed, the A3 model prints 267 × 420 mm and the A2 model 500 × 400 mm with up to 150 mm of height. If you decorate garments, a DTF printer is the better tool.

Options and customization

Plug to suit your country.
For larger items, see the A3 (267 × 420 mm) and A2 (500 × 400 mm) UV flatbed printers.

Machinery test report and outgoing-inspection video are provided with every unit. Free training is available at our factory in Wuhan.

Talk to an engineer

Tell us the material, thickness and the result you need. An engineer replies with a matched configuration and a quote.

Send your job details

Need a different setup?

This site shows only part of our range. Other powers and sizes, custom builds and everything around the machine are available on request.

Ask for the rest

Related guide

Wall printer buyer’s guide

Data

Specifications

A5 UV Flatbed Printer MW-A5UV (Epson L800) specifications
Model	MW-A5UV
Print head	Epson L800
Print area	120 × 210 mm
Print height	0–120 mm
Height measurement	One-key infrared, automatic
Colours	White and colour printed together
UV curing	LED UV lamp
Ink consumption	About 20 ml per m²
Operating system	Windows
Power supply	AC 100–230 V
Machine size (L × W × H)	500 × 370 × 270 mm
Weight	20 kg
Packing size (L × W × H)	530 × 400 × 300 mm, wooden case
Packed weight	28 kg
