A3 UV Flatbed Printer A3-19 (Epson L800)
Models · A3-19
A desktop A3 UV flatbed printer for small objects: it prints a 267 × 420 mm area on items up to 120 mm tall, measures the height with an infrared sensor and prints white plus colour, including raised relief effects. It uses an Epson L800 head with a six-colour CISS ink supply, AcroRIP software and a water- and air-cooled 30 W UV LED lamp, and weighs 46 kg. Choose it for phone cases, gifts, cards and signs; the A2 model takes larger and taller items, the A5 model is smaller and lighter.
- Print area
- 267 × 420mm
- Print height
- 0–120mm
- Resolution
- 2880 × 1440dpi
- Net weight
- 46kg
- 2-year whole-machine warranty
- Free operator training
- Built to order: voltage, plug, labels
- Prints a 267 × 420 mm area on objects up to 120 mm tall
- Infrared height measurement and anti-collision protection
- White ink and raised relief printing
- 6-colour CISS ink supply; about 20 ml of ink per m²
- Water- and air-cooled 30 W UV LED lamp
Overview
A UV flatbed printer prints straight onto objects laid on its bed, and a UV lamp cures the ink at once. The A3 model prints a 267 × 420 mm area on items up to 120 mm tall. An infrared sensor measures each object and sets the platform height, so you can switch from a phone case to a bottle or a crystal block without manual adjustment.
An Epson L800 head prints at up to 2880 × 1440 dpi from a six-colour continuous ink supply (CISS). The printer lays white under or over colours and can build raised relief textures. An A3 sheet takes about 3 minutes at 1440 dpi, and ink use is about 20 ml per square metre.
Configuration
- Head: Epson L800.
- Ink: 6-colour CISS with white.
- Curing: 30 W UV LED lamp, water and air cooled, rated for 3 years.
- Platform: aluminium, stepper-motor drive, touch-screen control and infrared height measurement.
- Protection: infrared anti-collision; head capping with moisturising solution.
- Components: TECO servo motor, Omron photoelectric sensors, SKF bearings, IGUS drag chain, Gates timing belt, Siemens and Schneider switches.
- Software: AcroRIP on Windows, with automatic ink-cost calculation and edge feathering.
- Power: AC 100–230 V.
- Size and weight: 670 × 670 × 510 mm, 46 kg net; 66 kg in an export wooden case.
Typical applications
Phone cases, USB drives, CDs, name plates, cards, crystal pendants, acrylic signs, bottles, cans, leather wallets and glass. It suits gift shops, personalisation services and short-run product decoration.
Options and customization
- Plug and voltage to suit your country.
- Colour configuration on request.
Free training is available at our factory in Wuhan.
Talk to an engineer
Tell us the material, thickness and the result you need. An engineer replies with a matched configuration and a quote.
Send your job detailsNeed a different setup?
This site shows only part of our range. Other powers and sizes, custom builds and everything around the machine are available on request.
Ask for the restRelated guide
Wall printer buyer’s guideData
Specifications
| Model | A3-19 |
|---|---|
| Print head | Epson L800 |
| Print area | 267 × 420 mm (platform 300 × 420 mm) |
| Print height | 0–120 mm, infrared height measurement |
| Resolution | 2880 × 1440 dpi |
| Print speed | About 3 min per A3 sheet at 1440 dpi |
| Ink supply | 6-colour CISS |
| White ink | Yes |
| Relief printing | Yes |
| Ink consumption | About 20 ml per m² |
| UV lamp | 30 W LED, water and air cooled; rated life 3 years |
| Platform | Touch-screen control with infrared height measurement; stepper motor drive |
| Head protection | Infrared anti-collision; capping with moisturising solution |
| Software | AcroRIP, Windows only (not macOS) |
| Power supply | AC 100–230 V; plug to suit your country |
| Machine size (L × W × H) | 670 × 670 × 510 mm |
| Packing size (L × W × H) | 700 × 700 × 620 mm, export wooden case with foam |
| Net weight | 46 kg |
| Gross weight | 66 kg |
| Key components | TECO servo motor, Omron sensors, SKF bearings, IGUS drag chain, Gates belt, Siemens and Schneider switches |
Print speed depends on resolution, colour set and image; confirm warranty terms for this model with us.
Wuhan Maxwave Laser Technology Co., Ltd. · sales@zerolineai.com · +44 7762 362563 · Specifications may change; confirm your configuration with us.
Fit
Materials & uses
Materials
- Plastic (ABS, PVC)
- Acrylic
- Glass
- Leather
- Crystal
- Ceramic tile
- Stone
- Metal
Applications
- Phone cases
- USB drives and CDs
- Name plates and cards
- Crystal and acrylic gifts
- Bottles and cans
- Leather wallets
FAQ
About this machine
How tall an object can it print on?
Up to 120 mm. An infrared sensor measures the object height and sets the platform, and an infrared anti-collision system protects the head.
Does it work with a Mac?
No. It runs AcroRIP on Windows; the software does not support macOS.
Can it print white and raised textures?
Yes. It prints white ink under or over colours and builds up layers for raised relief effects.
How much ink does it use?
About 20 ml per square metre of print, depending on the image and colour set.
What is the difference from the A2 model?
The A2 model has a larger 500 × 400 mm bed, 150 mm print height and up to two heads. The A3 is a compact desktop unit at 46 kg.
