Light-weight UV wall printer with black mast and compact base unit on a floor frame

Vertical wall printers

Mini Portable UV Wall Printer, 43 kg (Wheel Type)

A light-weight wheel-type UV wall printer: 43 kg net and 60 kg packed, light enough to send by air freight. It carries two Epson DX7 heads with CMYK or CMYK + white UV ink and prints 2.5 m high as standard (3 m optional) with unlimited width, with or without floor rails. It is the lightest wall printer in our range; for 3.5 m walls choose the wheeled 3.5 m model, and for more head options the 2025 wheel-type printer with guide rails.

Machine weight
43kg
Print height
2.5–3m
Resolution
2880dpi
Packed weight
60kg
Get a quote Test my part on it
  • 2-year whole-machine warranty
  • Free operator training
  • Built to order: voltage, plug, labels
  • 43 kg machine, 60 kg packed, suitable for air freight
  • Two Epson DX7 heads, CMYK or CMYK + white UV ink
  • 2.5 m × 6 m standard print size; 3 m height optional; width unlimited
  • Runs on wheels, with or without floor rails
  • Software installed and calibrated before delivery

Overview

The Mini Portable UV Wall Printer is built for mural painters who travel. The machine weighs 43 kg and ships at 60 kg, so you can send it by air instead of sea freight. A slim black mast carries the print carriage, and the compact base rolls on wheels. You can use it with or without floor rails.

Two Epson DX7 heads print CMYK or CMYK + white UV ink at up to 2880 dpi with a 3.0 pl droplet. White ink lets you print any colour on a coloured wall. The standard print size is 2.5 m high by 6 m wide, a 3 m height is available, and width is unlimited as the printer moves along the wall.

Configuration

  • Heads: two Epson DX7 heads.
  • Ink and curing: UV ink, cured by an LED UV lamp as it prints.
  • Wall sensing: ultrasonic probe that follows wall unevenness up to 3 cm.
  • Travel: wheels; floor rails optional.
  • Control: RIP software, installed and calibrated before delivery; USB 3.0 data link.
  • Power: single-phase AC 110–220 V, 50/60 Hz, 2000 W.
  • Weight: 43 kg net, 60 kg packed.

Typical applications

Mobile mural services, feature walls in homes and shops, and photo and art reproductions. It prints on painted walls, tile and glass. Speed is 8 m²/h in draft and standard modes and 5 m²/h in high-resolution mode.

Options and customization

  • CMYK or CMYK + white.
  • Print height 2.5 m or 3 m.
  • With or without floor rails.
  • Voltage and plug to suit your country.

We test every machine before shipment. It comes with our 2-year whole-machine warranty, free training at our factory in Wuhan and remote support.

Talk to an engineer

Tell us the material, thickness and the result you need. An engineer replies with a matched configuration and a quote.

Send your job details

Need a different setup?

This site shows only part of our range. Other powers and sizes, custom builds and everything around the machine are available on request.

Ask for the rest

Related guide

Wall printer buyer’s guide

Data

Specifications

Mini Portable UV Wall Printer, 43 kg (Wheel Type) specifications
Print headEpson DX7, double head
Colour modeCMYK or CMYK + white
InkUV ink, LED UV cured
Print size2.5 m × 6 m standard; 3 m high optional; width unlimited
TravelWheels; floor rails optional
Ink droplet3.0 pl
Resolution2880 dpi
Print speedDraft 8 m²/h; standard 8 m²/h; high resolution 5 m²/h
Wall-distance sensingUltrasonic, auto-adjusts for unevenness up to 3 cm
Data interfaceUSB 3.0
Power supplySingle-phase AC 110–220 V, 50/60 Hz, 2000 W
Operating temperature10–35 °C
Machine weight43 kg
Packed weight60 kg

The old page text also mentions 70 kg; the spec table lists 43 kg net and 60 kg packed. Confirm shipping weight for your configuration.

Wuhan Maxwave Laser Technology Co., Ltd. · sales@zerolineai.com · +44 7762 362563 · Specifications may change; confirm your configuration with us.

Fit

Materials & uses

Materials

  • Painted walls
  • Ceramic tile
  • Glass

Applications

  • Mobile mural services
  • Home and shop feature walls
  • Art and photo reproductions on walls

FAQ

About this machine

Can it be shipped by air?

Yes. At 60 kg packed it is light enough for air freight, which shortens delivery and can lower freight cost. Ask us for the packing dimensions for a freight quote.

Do I need the floor rails?

No. The printer runs on wheels and can be ordered with or without rails. Rails help keep long murals straight on uneven floors.

How much area does a set of ink print?

The manufacturer quotes 120–200 m² per set of ink. Actual coverage depends on the image and print mode.

Can it print on dark walls?

Yes, with the CMYK + white option. White ink lets you print light colours on dark or coloured backgrounds.

What training and support do I get?

We install and calibrate the software before delivery, test the machine, and offer free training at our factory plus remote support afterwards.
