Wheel-type wall printer with slim black column on its guide-rail frame, beside two printed portraits

Vertical wall printers

Wheel-Type UV Wall Printer with Guide Rails, 3 m (45 kg)

A 2025 light-weight UV wall printer that runs either on its own wheels or on guide rails, so you can set it up to suit the floor on site. It weighs 45 kg, breaks down into seven parts, assembles in 5–10 minutes and prints 3 m high with unlimited width in CMYK or CMYK + white. Choose it over the Track-Type 2-in-1 when portability matters more than floor printing or a 3.5 m height.

Print height: 3m
Machine weight: 45kg
Resolution: 2880dpi
Assembly time: 5–10min

2-year whole-machine warranty
Free operator training
Built to order: voltage, plug, labels

Runs on wheels or on guide rails, depending on the floor
45 kg machine; the print-head unit alone weighs 6.9 kg
Seven removable parts, 5–10 minutes to assemble
Prints 3 m high with unlimited width, CMYK or CMYK + white UV ink
Choice of Epson DX10, DX7, I1600 or I3200 heads

Overview

This is our 2025 light-weight UV wall printer for mural painters who move between sites. A slim black aluminium column carries the print carriage and a small control screen. The base can roll on its own wheels or run on guide rails, so you choose the set-up that suits the floor in front of the wall.

The printer prints 3 m high with unlimited width. Leave a 20 cm margin on every side of the image. It prints CMYK or CMYK + white UV ink at up to 2880 dpi, and a UV lamp cures each pass as it prints. Speed is 8 m²/h in draft and standard modes and 5 m²/h in high-resolution mode.

Configuration

Heads: Epson DX10, DX7, I1600 or I3200, chosen when you order.
Ink and curing: UV ink with a liquid-level alarm; UV lamp box on the carriage.
Positioning: distance sensor on the carriage keeps the head-to-wall gap.
Head care: electric capping station that keeps the heads moist overnight.
Structure: seven removable parts (main unit, base, support frame, floor rail, wheel rail, print head). Assembly takes 5–10 minutes.
Power: single-phase AC 110–220 V, 50/60 Hz, 2000 W; UPS power supply on request.
Weight: 45 kg machine, 110 kg packed with rails and frames in a 117 × 75 × 75 cm wooden case.

Typical applications

Portrait and photo murals, feature walls in homes, hotels, shops and cafés, and mobile mural services where one operator moves the printer between jobs.

Options and customization

Head type and CMYK or CMYK + white ink.
UPS power supply.
Voltage and plug to suit your country.

Every printer comes with our 2-year whole-machine warranty and free training at our factory in Wuhan.

Talk to an engineer

Tell us the material, thickness and the result you need. An engineer replies with a matched configuration and a quote.

Send your job details

Need a different setup?

This site shows only part of our range. Other powers and sizes, custom builds and everything around the machine are available on request.

Ask for the rest

Related guide

Wall printer buyer’s guide

Data

Specifications

Wheel-Type UV Wall Printer with Guide Rails, 3 m (45 kg) specifications
Print head	Epson DX10, DX7, I1600 or I3200 (option)
Colour mode	CMYK or CMYK + white
Ink	UV ink, UV lamp cured
Print size	3 m high × unlimited width
Print margin	20 cm top, bottom, left and right
Ink droplet	3.0 pl
Resolution	2880 dpi
Print speed	Draft 8 m²/h; standard 8 m²/h; high resolution 5 m²/h
Travel	Wheels or guide rails (two assembly options)
Assembly	7 removable parts: main unit, base, support frame, floor rail, wheel rail, print head
Print-head unit weight	6.9 kg
Head maintenance	Electric capping station
Ink supply	Liquid-level alarm
Data interface	USB 3.0
Power supply	Single-phase AC 110–220 V, 50/60 Hz, 2000 W; UPS power supply on request
Operating temperature	10–35 °C
Machine height	3 m
Machine weight	45 kg
Packed weight	110 kg, including floor rails, support frame and wheel rails
Packing size	117 × 75 × 75 cm, wooden case

Head type affects price and speed; confirm the head and ink configuration with us.

Wuhan Maxwave Laser Technology Co., Ltd. · sales@zerolineai.com · +44 7762 362563 · Specifications may change; confirm your configuration with us.

Fit

Materials & uses

Materials

Painted interior walls

Applications

Home and hotel feature walls
Portrait and photo murals
Shop and café decoration
Mobile mural services

FAQ

About this machine

When should I use the wheels and when the guide rails?

The printer can be assembled either way to suit the site. Wheels give a quick set-up on a flat floor; guide rails keep the line straight on uneven floors and long walls. Both are in the standard package.

How long does set-up take?

The machine splits into seven parts and goes together in 5–10 minutes. The heaviest single item, the print-head unit, weighs 6.9 kg.

Which print head should I choose?

It is offered with Epson DX10, DX7, I1600 or I3200 heads. Tell us your typical walls and monthly output and we will recommend one.

Can it run where mains power is unreliable?

A UPS power supply can be added on request. Standard supply is single-phase AC 110–220 V.

How does it compare with the Track-Type 2-in-1?

This model is lighter (45 kg against 120 kg) and quicker to assemble. The Track-Type 2-in-1 prints up to 3.5 m high and also converts to floor printing.
