3D Vertical UV Wall Printer, Epson DX7 Double Head

A rail-mounted vertical wall printer with two Epson DX7 heads and UV ink, built to print any colour on any colour of wall using its optional white channel (CMYK + W). It prints 2.5 m high and 6 m wide as standard, with unlimited width, and runs on 110–220 V. It differs from the Touch-Screen 3D Wall Printer by its UV ink system and wide-voltage supply, and from the Mini Portable UV printer by its fixed rail base instead of a light wheeled frame.

Print height: 2.5m
Standard print width: 6m
Resolution: 2880dpi
Supply voltage: 110–220V

2-year whole-machine warranty
Free operator training
Built to order: voltage, plug, labels

Two Epson DX7 heads with UV ink
CMYK or CMYK + white for printing on coloured backgrounds
2.5 m × 6 m standard print size, width unlimited
Wide-voltage supply: AC 110–220 V
Every machine tested by a technician before shipment

Overview

The 3D Vertical UV Wall Printer prints images straight onto walls with UV-curing ink. The machine stands on a floor rail in front of the wall. The carriage prints a vertical band, then the machine moves along the rail for the next band. Standard print size is 2.5 m high and 6 m wide, and width is unlimited when you move the rail.

Two Epson DX7 heads print at up to 2880 dpi with a 3.0 pl droplet. With the optional white channel (CMYK + W) the printer can lay down any colour on any colour of wall. UV ink cures as it prints, so the image is dry, waterproof and resistant to sunlight without a separate coating step.

Configuration

Heads: two Epson DX7 heads, each colour on its own ink supply.
Curing: LED UV lamp on the carriage.
Wall sensing: ultrasonic probe that keeps the head-to-wall gap and follows unevenness up to 3 cm.
Drive: servo motors with a power-off brake.
Control: RIP colour-management software, installed and calibrated before delivery; USB 3.0 data link.
Power: single-phase AC 110–220 V, 50/60 Hz, 2000 W.
Transport: the frame folds to fit in a car, van or SUV.

Typical applications

Murals on coloured or dark walls, hotel, restaurant and shop interiors, photo prints on walls, and decoration on tile and glass. Print speed is 8 m²/h in draft and standard modes and 5 m²/h in high-resolution mode.

Options and customization

CMYK or CMYK + white.
Voltage and plug to suit your country.

We test every machine before shipment. It comes with our 2-year whole-machine warranty, free training at our factory in Wuhan and remote support.

Talk to an engineer

Tell us the material, thickness and the result you need. An engineer replies with a matched configuration and a quote.

Send your job details

Need a different setup?

This site shows only part of our range. Other powers and sizes, custom builds and everything around the machine are available on request.

Ask for the rest

Related guide

Wall printer buyer’s guide

Data

Specifications

3D Vertical UV Wall Printer, Epson DX7 Double Head specifications
Print head	Epson DX7, double head
Colour mode	CMYK or CMYK + white
Ink	UV wall ink, LED UV cured
Print size	2.5 m × 6 m standard; width unlimited
Ink droplet	3.0 pl
Resolution	2880 dpi
Print speed	Draft 8 m²/h; standard 8 m²/h; high resolution 5 m²/h
Wall-distance sensing	Ultrasonic, auto-adjusts for unevenness up to 3 cm
Drive	Servo motors with power-off brake
Data interface	USB 3.0
Power supply	Single-phase AC 110–220 V, 50/60 Hz, 2000 W
Operating temperature	10–35 °C
Transport	Folding frame

Weight and packing size on request.

Wuhan Maxwave Laser Technology Co., Ltd. · sales@zerolineai.com · +44 7762 362563 · Specifications may change; confirm your configuration with us.

Fit

Materials & uses

Materials

Painted walls
Coloured walls
Ceramic tile
Glass

Applications

Murals on coloured or dark walls
Hotel, restaurant and shop interiors
Photo prints on walls
Glass and tile decoration

FAQ

About this machine

Can it print on dark or coloured walls?

Yes, when ordered with CMYK + white. The white channel lets it print light colours on any background colour.

How fast does it print?

The spec sheet gives 8 m²/h in draft and standard modes and 5 m²/h in high-resolution mode. The old page also quoted up to 15 m²/h; plan your jobs on the spec-sheet figures.

How much area does a set of ink cover?

The manufacturer quotes 120–200 m² per set of ink, depending on image coverage and print mode.

Is the machine checked before it ships?

Yes. A technician tests every machine before shipment, and we provide remote training and support for as long as you use it.
